TINYLOC FALCONRY TRANSMITTER F22 433 MHz

Select Fixing

185'00 € 215'00 €
(Ref. TX050XMI)

Powerful radio tracking transmitter of 7.9 gr weight for falconry and birds over 450 gr, with 7 days autonomy and over 80 km. scope in optimal weather conditions. The only one with the CE mark. Only available in the legal frequencies: from 433.050 up to 434.790 MHz.

Quantity

Overview Specs

Radio location transmitter compatible with the R1 + receptor. Where power and lightness come together. Ideal for birds over 450 grams. Battery operated type 1/3N, which provides a range of 7 days. The low battery detector will warn us 2 days before the battery is fully depleted, making a double tone.

• Its weight is 8.2 gr. mounted to leg, and 8.7 gr. mounted tail (battery included).
• The transmitter has a LED light that let you know when it is operating. This system can be very useful in night searches.
• 433 MHz version is the most powerful legal transmitter that currently exists in the market. Its tubular shape and threaded cap system battery allows to use it to paw or tail when its owner wishes. 216 MHz version is available for countries where this frequency is permitted.
• With magnetic switch.

BIRD SPECIES

Some of the raptors using this transmitter are:

• Goshawk
• Peregrine falcon
• Sacre
• Gyrfalcon
• Harris

F22 433 MHz

FREQUENCY RANGE

UE/AUS/NZ (433.050-434.790 MHz). Meets CE Mark  (not legal in the USA)

AUTONOMY

7 DAYS (2 LAST DAYS WITH LOW BATTERY LEVEL MODE)

RADIO TRACKING RANGE

5 to 25 km – tracking from ground.
25 to 40 km – tracking from 3-4 mts high
40 to 80 km – tracking from higher

POWER SUPPLY

3 v. / 1 BATTERY 1/3N

POWER EMISSION

10 Mw

PROTECTIÓN RATE

IP67 (waterproof)

WEIGHT WITHOUT  BATTERIES

7,9 gr. (without fixation)

DIMENSIONS

26 cm. length (plus 2 cm. transmitter body)

OPERATING TEMPERATURE

-15ºC to 50ºC

STORAGE TEMPERATURE

-20ºC to 70ºC

TURNING ON /BLINKER

Magnetic (magnet) and with battery / Power indicator lighted LED.

COMPATIBLE RECEIVER

TINYLOC R1+ 433 MHz
Any other manufacturer receiver working on frequencies 433 and 434 MHz.
